原我單位三筒烘干機技術參數備份：
| 設備型號 | 尺寸M | 生產率T | 終水分 | 耗煤量（KG/T砂） | 功率（KW） |
| AQS-623 |
1.7×1.8 |
3-5 | <0.5% | 5-7 | 4.0 |
| AQS-625 |
2.1×2.2 |
4-6 |
<0.5% | 5-7 | 5.5 |
| AQS-628 | 2.2×2.4 | 6-8 | <0.5% | 6-8 | 7.5 |
| AQS-6210 | 2.5×2.7 | 8-12 | <0.5% | 8-10 | 4×2 |
| AQS-6215 | 2.8×3.0 | 14-16 | <0.5% | 8-10 | 5.5×2 |
| AQS-6220 | 3.0×4.0 | 18-22 | <0.5% | 8-10 | 4×4 |
| AQS-6225 | 3.2×4.5 | 23-26 | <0.5% | 8-12 | 5.5×4 |
| AQS-6230 | 3.0×6.0 | 28-35 | <0.5% | 8-12 | 7.5×4 |
| AQS-6250 | 3.2×7.0 | 48-55 | <0.5% | 8-12 | 11×4 |
| AQS-6280 | 3.8×8.0 | 70-80 | <0.5% | 8-12 | 15×4 |
| AQS-6250×2 | 4.2×9.0 | 98-110 | <0.5% | 8-12 | 22×4 |
| 型號 | 直徑(米) | 長度(米) | 體積(m³) | 時產量(T/H) | 初始水分 | 終水分 | 約耗氣量(m³) | 參考功率(KW) |
| AQS-3 | 1.6 | 1.8 | 3.5 | 3-5 | ≤15% | ≤0.8% | 18-35 | 4 |
| AQS-5 | 1.8 | 2 | 4.9 | 4-6 | ≤15% | ≤0.8% | 29-58 | 5.5 |
| AQS-8 | 2 | 2.3 | 6.9 | 6-9 | ≤15% | ≤0.8% | 46-93 | 7.5 |
| AQS-10 | 2.2 | 2.5 | 9 | 9-11 | ≤15% | ≤0.8% | 58-116 | 11 |
| AQS-15 | 2.5 | 2.7 | 12.6 | 12-16 | ≤15% | ≤0.8% | 87-175 | 5.5×2 |
| AQS-20 | 2.5 | 3.6 | 16.7 | 16-21 | ≤15% | ≤0.8% | 116-233 | 7.5×2 |
| AQS-25 | 2.5 | 4.5 | 21 | 19-26 | ≤15% | ≤0.8% | 145-290 | 5.5×4 |
| AQS-30 | 2.6 | 5 | 25.2 | 23-31 | ≤15% | ≤0.8% | 175-349 | 7.5×4 |
| AQS-35 | 2.6 | 5.8 | 29.3 | 27-36 | ≤15% | ≤0.8% | 204-407 | 7.5×4 |
| AQS-40 | 2.8 | 6 | 35 | 32-43 | ≤15% | ≤0.8% | 233-465 | 11×4 |
| AQS-50 | 3 | 6.2 | 41.7 | 38-51 | ≤15% | ≤0.8% | 290-581 | 11×4 |
| AQS-60 | 3.2 | 7 | 53.5 | 49-65 | ≤15% | ≤0.8% | 349-698 | 15×4 |
三筒烘干機技術參數（備份）
| 型號Model | 單臺產量(t/h) |
終水分 (%) |
體積 (m³) |
燃焦量 (kg/t) |
主機功率 (kw) |
單機體積 (立方米) |
||||
| 黃沙 | 河沙 | 海沙 | 石英砂 | 鑄造砂 | ||||||
| AQS623 | 3-5 | 3-3.5 | 2.5-3 | 4-5 | 3-4 | ＜0.5% | 3.6 | 5-7 | 4 | 3.5 |
| AQS625 | 5-6 | 4.5-5.8 | 4.5-5 | 5-7 | 5-6 | ＜0.5% | 7.2 | 5-7 | 3×2 | 7.5 |
| AQS628 | 8-9 | 7.5-8.5 | 7-8 | 9-10 | 8.5-10 | ＜0.5% | 10 | 6-8 | 4×2 | 12.6 |
| AQS6210 | 10-12 | 10-11 | 9-10 | 11-15 | 10-13 | ＜0.5% | 12.8 | 8-10 | 4×2 | 15.6 |
| AQS6215 | 15-17 | 15-16 | 14-15 | 17-20 | 16-19 | ＜0.5% | 19.8 | 8-10 | 5.5×2 | 19 |
| AQS6220 | 21-23 | 20-22 | 20-21 | 25-27 | 24-26 | ＜0.5% | 28.5 | 8-10 | 4×4 | 29.5 |
| AQS6225 | 25-28 | 23-25 | 22-25 | 33-35 | 32-35 | ＜0.5% | 32.2 | 8-12 | 5.5×4 | 37 |
| AQS6230 | 30-35 | 29-32 | 28-32 | 40-45 | 38-43 | ＜0.5% | 42.4 | 8-12 | 7.5×4 | 42.5 |
| AQS6250 | 48-52 | 45-50 | 42-48 | 55-60 | 52-56 | ＜0.5% | 56.3 | 8-12 | 15×4 | 73.8 |
| AQS6280 | 65-72 | 62-68 | 60-67 | 85-92 | 83-90 | ＜0.5% | 81.4 | 8-12 | 22×4 | 110.8 |
| AQS6250×2 | 100-110 | 92-100 | 90-98 | 125-130 | 120-128 | ＜0.5% | 124.7 | 8-12 | 30×4 | 150.8 |
| 設備型號 | 尺寸M | 生產率T/H | 初始水分 |
終水分 |
參考功率（KW） |
| AQS-3 |
1.7×1.8 |
2.4-3.8 | ≤15% | ≤0.8% | 4.0 |
| AQS-5 |
2.1×2.2 |
4.4-7.0 |
≤15% | ≤0.8% |
3×2 |
| AQS-8 | 2.2×2.4 | 5.3-8.4 | ≤15% | ≤0.8% | 3×2 |
| AQS-10 | 2.5×2.7 | 7.7-12.2 | ≤15% | ≤0.8% | 5.5×2 |
| AQS-15 | 2.5×4.0 | 11.4-18 | ≤15% | ≤0.8% | 5.5×2 |
| AQS-20 | 2.8×4.0 | 14.2-22.8 | ≤15% | ≤0.8% | 5.5×4 |
| AQS-25 | 2.8×6.0 | 21.3-34 | ≤15% | ≤0.8% | 5.5×4 |
| AQS-30 | 3.0×6.0 | 24.5-39 | ≤15% | ≤0.8% | 7.5×4 |
| AQS-35 | 3.0×7.0 | 28.5-45.7 | ≤15% | ≤0.8% | 7.5×4 |
| AQS-40 | 3.2×7.0 | 32.5-52 | ≤15% | ≤0.8% | 11×4 |
| AQS-50 | 3.2×8.0 | 37-59 | ≤15% | ≤0.8% | 11×4 |
| AQS-60 | 3.6×8.0 |
47-75 |
≤15% | ≤0.8% | 15×4 |
| AQS-80 | 3.6×10 | 59-94 | ≤15% | ≤0.8% | 18.5×4 |
| AQS-100 | 3.6×14 | 80-128 | ≤15% | ≤0.8% | 22×4 |
| 型號 | 生產率 | 水分 | 耗標煤 | 功率KW |
|---|---|---|---|---|
| AQS-3 | 3t/h | <0.8% | 42kg/h | 4.0 |
| AQS-5 | 5t/h | <0.8% | 72kg/h | 5.5 |
| AQS-8 | 8t/h | <0.8% | 115kg/h | 7.5 |
| AQS-10 | 10t/h | <0.8% | 143kg/h | 2×5.5 |
| AQS-20 | 20t/h | <0.8% | 286kg/h | 4×5.5 |
| AQS-30 | 30t/h | <0.8% | 430kg/h | 4×7.5 |
| AQS-50 | 50t/h | <0.8% | 715kg/h | 4×11 |
| AQS-80 | 80t/h | <0.8% | 1145kg/h | 4×18.5 |
| AQS-100 | 100t/h | <0.8% | 1431kg/h | 4×22 |
